McIntosh MA5300
Integrētais pastiprinātājs MA5300 ir pierādījums tam, ka liela skaņa var būt mazos korpusos. Tas ir McIntosh mazākais metāla korpusā integrētais pastiprinātājs gan jaudas, gan fiziskā izmēra ziņā, padarot to par ideālu izvēli mazākām telpām vai tiem, kas tikko sāk veidot mājas audio sistēmu. Tas ir diskrēts pastiprinātājs, kas nodrošina 100 vatus kanālā 8 omu skaļruņos vai 160 vatus kanālā 4 omu skaļruņos. Jauni divu skalu zilie vatu mērītāji sniedz precīzu izejas jaudas nolasījumu gan 4, gan 8 omu pretestībai.
FTC Power Output Rating 100 W
Power Output per Channel 100 W into 8 ohms 160 W into 4 ohms
Number of Channels 2
Rated Power Band 20Hz to 20kHz
Total Harmonic Distortion 0.005%
Dynamic Headroom 1.8dB
Frequency Response +0,-0.5dB 20Hz to 20kHz
Frequency Response, +0, -3dB 10Hz to 100kHz
Sensitivity Phono (Moving Coil) N/A
Sensitivity Phono (Moving Magnet) 2.5mV
Sensitivity High Level (Balanced / Unbalanced) 0.5V/0.25V
Sensitivity (Power Amp input) 1V
Signal To Noise Ratio (Moving Coil) N/A
Signal To Noise Ratio (Moving Magnet) 82dB
Signal To Noise Ratio (High Level) 95dB
Signal To Noise Ratio (Power Amp input) 110dB
Input Impedance (Balanced / Unbalanced) 20K/20K
Damping Factor 8 ohms: >200 4 ohms: >100
Maximum Output (Balanced / Unbalanced) 8V Unbalanced
CONNECTIVITY
Balanced Input 1
Unbalanced Input 4
Phono Input Moving Coil 0
Phono Input Moving Magnet 1 (fixed loading)
Upgradeable Digital Audio Module Yes: DA1
Digital Coaxial Input 2
Digital Optical Input 2
Digital MCT Input 1
Digital USB Input 1
HDMI (ARC) Input 0
Balanced Variable Output 0
Unbalanced Fixed Output 0
Unbalanced Variable Output 1
Headphone Output 1/4" High Drive with Headphone Crossfeed Director (HXD®)
Subwoofer Output 0
AM/FM Tuner option No
Home Theater PassThru Yes
Unbalanced Analog Connector Type - Standard
Speaker Binding Post Type - Standard
Service Port 1
DIGITAL AUDIO SPECIFICATIONS
Digital-to-Analog Converter (DAC) Type 8-channel, 32-bit/384kHz PCM/DSD, Quad Balanced
Digital Coaxial Input Sample Rate 24-bit/44.1kHz to 192kHz
Digital Optical Input Sample Rate 24-bit/44.1kHz to 192kHz
Digital MCT Input Sample Rate 16-bit/44.1kHz (CD) DSD64 (SACD)
Digital USB Input Sample Rate 32-bit/44.1kHz to 384kHz (PCM)
DSD64, DSD128, DSD256, DXD352.8kHz, DXD384kHz
CONTROL
Tone Controls Bass and Treble
Tone Bypass and Input Assign - Yes
RS232 Control Input - Yes
Power Control Output 1 Main
Rear Panel Data Port 2
Rear Panel IR Sensor Input - Yes
Input Level Match - Yes
GENERAL SPECIFICATIONS
Vacuum Tube or Solid State - Solid State
Output Type - Direct Coupled
Output Meters - Yes
Dual Layer Chassis - Yes
Chassis Finish - Black painted steel
McIntosh Monogrammed Heatsinks™ - Yes
Power Requirement 120V 50/60Hz, 2.3A
Standby Power Requirement <0.25 Watts
WEIGHTS & DIMENSIONS - Unit Dimensions (W x H x D)
17-1/2" (44.45cm) x 6" (15.2cm) x 18-3/4" (47.6cm)
Unit Weight
38 lbs (17.2 kg)
Shipping Weight
55.5 lbs (25.2 kg)
